MILTECH 610 Military Fast Ethernet Unmanaged Switch - 8 Port with LED indicators

Key Features
Product Type:Ethernet switch
Management:Unmanaged
Ports:
8 x 10/100M Copper
Connectors:
Power: D38999
LAN: D38999
Designed to Meet:MIL-STD-1275 | MIL-STD-704 | MIL-STD-810 | MIL-STD-461 | IP67
Dimensions:10.59" X 5.24" X 2.82"269mm X 133mm X 71.7mm
Weight:52.91oz1500g
Operating Temp.:-45°C to 85°C
Power input:24VDC (18 - 32VDC), 2.8W

The MILTECH 610 is an 8 x 10/100Mbp unmanaged Fast Ethernet switch with 8 D38999 circular connectors.

Custom Designed Solutions

For all your requirements, we’ll custom design a solution to fit your needs

CONTACT US TODAY
Standard Configurations
Model Description
1-610-000 MILTECH610, military Rugged, 8 x 10/100TX, Switch
MILTECH 610 Additional configurations available
Description

Ideal for battlefield C4ISR, voice, video, and sensor data acquisition, and communications in military platforms, the MILTECH 610 serves as robust Fast Ethernet switches for providing unmanaged local area network (LAN) connectivity to IP-enabled computing and net-centric devices. The MILTECH 610 is equipped with 8 LED indicator lights for easy observation of link status on each port.

It operates on readily available 24VDC power and supports MIL-STD1275 so that it may be powered directly from any available battery in the field. The unit’s mechanical packaging enhancements, including ruggedized deliver IP76 and MIL-STD-810F airborne and ground environmental compliance for high reliability.

Tailored Products to Meet Your Requirements
mots

Modified Off The Shelf Solutions

All of our products can be configured to your specific requirements. Customers are invited to work with a design engineer to define the output, input range, protection limits and dimensions of the power solution which best meets their project needs. This can frequently be accomplished without NRE. Use the contact form to submit a request, or contact us to discuss your requirements. For our US team call (603) 267-8865, for our European team call: +41-41-740-4554. Configurations created for specific requirements will be assigned a new variant part number.
