Ethernet Switches
Managed
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 9132managed28 x 100/1000M Fiber MIL-STD-810, MIL-STD-461
MILTECH 1.2T3UVPXmanaged10 x 100G
9 x 25G 3U3U12VDC
3.3VAUXV, 90WMIL-STD-461, SOSA™, VITA 48.2
MILTECH 2000managed2 x 10/100/1000M Copper245.4" X 159.3" X 75.2"6233.16mm X 4046.22mm X 1910.08mm24VDC (12-48V)WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 20G3UVPX managed12 x 1G Copper
8 x 1G SGMII
4 x 1G Fiber3U3U5VDC
12V, 12 or 15WMIL-STD-810, MIL-STD-461
MILTECH 24FOmanaged24 x 1G Fiber8.44" X 3.71" X 1.98"214.3mm X 94.3mm X 50.2mm28VDC (18-40VDC)MIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 2T6UVPXmanaged14 x 100G
16 x 25G
15 x 10G 6U6U12VDC
3.3VDC, WMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 320G3UVPXmanaged32 x 10G 3U3U12VDC
3.3VDC, 39WMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 322G3UVPXmanaged 2 X 40G and 24 x 10G 3U3U12V
3.3V, Typical 29W, Maximum 35WWMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 324G3UVPX managed6 x 40 GKR + 7 x 10G 3U3U12VDC
3.3VDC, Typical 29W, Maximum 35WWMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 326G3UVPXmanaged 6 X 40G + 8 x 10G 3U3U12VDC
3.3VDC, Typical 29W, Maximum 35WWMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 404managed6 ports: Copper, USB2.0, Serial, I/O4.61" X 4.85" X 0.98"117mm X 123.2mm X 25mm24VDC (18-28VDC), 15WMIL-STD-1275, MIL-STD-810, MIL-STD-461, IP68
MILTECH 410managed10 ports: USB, Copper, I/O, USB3.14.54" X 3.58" X 1.06"115.2mm X 91mm X 26.9mm24VDC (12-32VDC), 5WMIL-STD-1275, MIL-STD-810, MIL-STD-461, IP68
MILTECH 800G3UVPXmanaged6 x 100G
8 x 25G 3U3U12V
3.3V, Typical 85WMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 9012C-005managed16 x 10/100/1000M Copper13.5" X 9.49" X 3.15"342.9mm X 241.05mm X 80.01mm24Vdc Nominal (18-36V)WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461,
MILTECH 9030managed 24 x 1G Copper
1 x 1G Fiber
5 x 10G Copper17.05" X 7.76" X 3.78"433mm X 197mm X 96mm24VDC (18-32VDC), 24VDC (18-32V)WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, 67
MILTECH 904managed4 x 10/100/1000M Copper4.02" X 2.89" X 1.42"102mm X 73.3mm X 36mm24VDC (16-36VDC), 5WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP68
MILTECH 907managed5 x 10/100/1000M Copper4.45" X 2.13" X 1.57"113mm X 54mm X 40mm24VDC (16-36VDC), 5WMIL-STD-810, MIL-STD-461
MILTECH 908managed8 x 10/100/1000M Copper10.59" X 5.23" X 2.82"269mm X 132.9mm X 71.7mm24VDC (18-32VDC), 7WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 9116managed12 x 10G Copper
4 x 10G Fiber16.77" X 8.03" X 2.76"426mm X 204mm X 70mm24VDC (18-12VDC), 87WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 912managed12 x 10/100/1000M Copper7.01" X 5.35" X 1.85"178.1mm X 136mm X 47.1mm24VDC (16-36VDC), 7WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 918managed8 x 10/100/1000M Copper3.94" X 3.5" X 1.42"100mm X 89mm X 36mm24VDC (16-36VDC), 8WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP68
MILTECH 9224managed24 x 10/100/1000M 9.59" X 2.87" X 3.7"243.5mm X 72.9mm X 94mm24VDC (18vdc - 2vdc)WMIL-STD-810, MIL-STD-461
MILTECH 928managed8 x 10/100/1000M Copper11.3" X 5.79" X 1.97"287mm X 147mm X 50mm24VDC (18-32VDC), 7WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 948managed8 x 10/100/1000M Copper
2 x 1G Fiber8.23" X 5.75" X 2.48"209mm X 146mm X 63mm24VDC (18-32VDC), 7WMIL-STD-1275, MIL-STD-704, IP67
MILTECH-910-PoEmanaged8 x 10/100/1000M Copper + PoE10.59" X 5.24" X 2.8"269mm X 133mm X 71mm24VDC (18-32VDC), 330WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP68
Unmanaged
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 304unmanaged4 x 10/100M Copper3.24" X 2.09" X 1.02"82.2mm X 53mm X 26mm28VDC, 2WMIL-STD-810, MIL-STD-461, IP68
MILTECH 308unmanaged8 x 10/100M Copper3.24" X 2.52" X 1.02"82.2mm X 64.1mm X 26mm5VDC, 2WMIL-STD-810, MIL-STD-461, IP68
MILTECH 402unmanaged2 x 10/100M Copper + PoE
3 x 10/100M Copper3.94" X 3.71" X 1.34"100mm X 94.2mm X 34.1mmVDC (10-16.8VDC), 35WMIL-STD-810, MIL-STD-461, IP67
MILTECH 470unmanaged1 x 10/100/1000M 11.64" X 7.06" X 2.37"295.6mm X 179.3mm X 60.2mm24VDC (12-48VDC), 114WMIL-STD-810, MIL-STD-461, IP68
MILTECH 610unmanaged8 x 10/100M Copper10.59" X 5.24" X 2.82"269mm X 133mm X 71.7mm24VDC (18-32VDC), 2.8WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 610-PoEunmanaged8 x 10/100M Copper + PoE10.59" X 5.24" X 2.82"269mm X 133mm X 71.7mm24VDC (18-32VDC), 5WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 708unmanaged8 x 10/100M Copper10.59" X 5.24" X 2.82"269mm X 133mm X 71.7mm24VDC (18-32VDC), 2.8WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
Embedded Ethernet Switches
Managed
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 9113managed12 x 10/100/1000M Copper
2 x 1G SGMII3.82" X 2.75" X 0.78"97.03mm X 69.85mm X 19.81mmVDC (6-36VDC)
3.3VDC, 9.3WMIL-STD-810, MIL-STD-461
MILTECH 9124managed24 x 1G Copper3.58" X 2.56"91mm X 65mm MIL-STD-810, MIL-STD-461, IP67
MILTECH 9126managed24 x 1G Copper
2 x 1G Fiber5.12" X 3.43"130mm X 87mm15WMIL-STD-810, MIL-STD-461, IP67
MILTECH 9128managed24 x 1G Copper
4 x 10G Fiber3.54" X 3.54"90mm X 90mm MIL-STD-810, MIL-STD-461, IP67
MILTECH 9136managed40 ports: Copper, SGMII, QSGMII, Fiber3.43" X 3.43"87mm X 87mm MIL-STD-810, MIL-STD-461, IP67
MILTECH 919managed8 x 10/100/1000M Copper
1 x 100/1000M Fiber4.21" X 1.89" X 0.75"107mm X 48mm X 19mm MIL-STD-810, MIL-STD-461, IP68
Unmanaged
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 309unmanaged8 x 10/100M Copper2.8" X 1.7" X 0.45"71mm X 43.18mm X 11.4mm2WMIL-STD-810, MIL-STD-461, IP68
MILTECH 718unmanaged8 x 10/100/1000M Copper2.76" X 1.57"70mm X 40mm MIL-STD-810, MIL-STD-461, IP68
MILTECH M512unmanaged1 x USB3.12.56" X 1.1" X 0.75"65mm X 28mm X 19mm MIL-STD-810, MIL-STD-461
USB HUBS and Storage Devices
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 16SERunmanaged16 x USB2.03.94" X 3.5" X 1.57"100mm X 88.9mm X 40mm24VDC (16-36VDC), 4WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 2022managed6 ports: Copper, Serial, I/O4.02" X 2.89" X 1.42"102.11mm X 73.41mm X 36.07mm24VDC (12-48VDC), 5WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461
MILTECH 300managed8 ports: USB2/3, Copper, I/O2.87" X 1.5" X 0.43"73mm X 38mm X 11mm MIL-STD-810, MIL-STD-461, IP68
MILTECH 303unmanaged8 ports: USB3.1/3.2, Copper, I/O3.54" X 2.76" X 0.83"89.8mm X 70.2mm X 21.2mm5VDCMIL-STD-810, MIL-STD-461, IP68
MILTECH 306unmanaged7 x USB2.03.24" X 2.52" X 1.02"82.2mm X 64.1mm X 26mm5VDC, 2WMIL-STD-810, MIL-STD-461, IP68
MILTECH 404managed6 ports: Copper, USB2.0, Serial, I/O4.61" X 4.85" X 0.98"117mm X 123.2mm X 25mm24VDC (18-28VDC), 15WMIL-STD-1275, MIL-STD-810, MIL-STD-461, IP68
MILTECH 406unmanaged16 ports: Copper, USB2.0, Serial, I/O3.82" X 3.07" X 0.98"97mm X 78mm X 25mm5VDC, 5WMIL-STD-810, MIL-STD-461, IP68
MILTECH 410managed10 ports: USB, Copper, I/O, USB3.14.54" X 3.58" X 1.06"115.2mm X 91mm X 26.9mm24VDC (12-32VDC), 5WMIL-STD-1275, MIL-STD-810, MIL-STD-461, IP68
MILTECH 420managed1 x USB2.0
3 x USB2.0
2 x USB2.03.23" X 3.5" X 0.87"82.04mm X 88.9mm X 22.1mm IP68
MILTECH 430Emanaged7 ports: , USB7.01" X 5.04" X 1.87"178mm X 128mm X 47.5mmVDC (10-18VDC), 288WMIL-STD-810, MIL-STD-461
MILTECH 470unmanaged1 x 10/100/1000M 11.64" X 7.06" X 2.37"295.6mm X 179.3mm X 60.2mm24VDC (12-48VDC), 114WMIL-STD-810, MIL-STD-461, IP68
MILTECH 471managed2 x 10/100/1000M Copper
5 x USB2/3
1 x USB2/36.84" X 8.02" X 2.37"173.8mm X 203.8mm X 60.2mm24VDC (18-48VDC), 489WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP 68
MILTECH 477managed x 10/100/1000M Copper
x USB2.010.65" X 6.96" X 2.25"270.4mm X 176.8mm X 57.2mm28VDC (18-48VDC), 5.4WMIL-STD-1275, MIL-STD-810, MIL-STD-461
MILTECH 8Punmanaged8 x USB2.04.49" X 3.74" X 1.44"114mm X 95mm X 36.5mm24VDC (18-32VDC), 80WMIL-STD-810, MIL-STD-461
MILTECH M128unmanaged1 x USB3.12.56" X 1.1" X 0.75"65mm X 28mm X 19mm MIL-STD-810, MIL-STD-461, IP67
MILTECH M256unmanaged1 x USB3.12.56" X 1.1" X 0.75"65mm X 28mm X 19mm MIL-STD-810
MILTECH M512unmanaged1 x USB3.12.56" X 1.1" X 0.75"65mm X 28mm X 19mm MIL-STD-810, MIL-STD-461
MILTECH M64unmanaged1 x USB3.12.56" X 1.1" X 0.75"65mm X 28mm X 19mm MIL-STD-810, MIL-STD-461, IP67
MILTECH VGAunmanaged1 x USB2/3
1 x Serial3.01" X 2.81" X 0.97"76.4mm X 71.4mm X 24.7mm5VDCMIL-STD-810, MIL-STD-461, IP68
Networking VPX
VPX 6U
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 2T6UVPXmanaged14 x 100G
16 x 25G
15 x 10G 6U6U12VDC
3.3VDC, WMIL-STD-810, MIL-STD-461, SOSA™
VPX 3U
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 1.2T3UVPXmanaged10 x 100G
9 x 25G 3U3U12VDC
3.3VAUXV, 90WMIL-STD-461, SOSA™, VITA 48.2
MILTECH 20G3UVPX managed12 x 1G Copper
8 x 1G SGMII
4 x 1G Fiber3U3U5VDC
12V, 12 or 15WMIL-STD-810, MIL-STD-461
MILTECH 320G3UVPXmanaged32 x 10G 3U3U12VDC
3.3VDC, 39WMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 322G3UVPXmanaged 2 X 40G and 24 x 10G 3U3U12V
3.3V, Typical 29W, Maximum 35WWMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 324G3UVPX managed6 x 40 GKR + 7 x 10G 3U3U12VDC
3.3VDC, Typical 29W, Maximum 35WWMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 326G3UVPXmanaged 6 X 40G + 8 x 10G 3U3U12VDC
3.3VDC, Typical 29W, Maximum 35WWMIL-STD-810, MIL-STD-461, SOSA™
MILTECH 800G3UVPXmanaged6 x 100G
8 x 25G 3U3U12V
3.3V, Typical 85WMIL-STD-810, MIL-STD-461, SOSA™
Media Converters
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 1000 Seriesmanaged2 x 10/100/1000M Copper
2 x 100/1000M Fiber6.69" X 5.94" X 2.4"170mm X 151mm X 61mm24VDC (18-32VDC)
VAC (85-265VAC), 2.8WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 1100managed2 x 1/10G Copper
2 x 1/10G Fiber6.68" X 5.96" X 2.83"169.7mm X 151.3mm X 71.9mm24VDC (18-32VDC), 11WMIL-STD-1275, MIL-STD-704, MIL-STD-810, IP67
MILTECH 948managed8 x 10/100/1000M Copper
2 x 1G Fiber8.23" X 5.75" X 2.48"209mm X 146mm X 63mm24VDC (18-32VDC), 7WMIL-STD-1275, MIL-STD-704, IP67
Rugged Routers
SeriesManagementPortsDimensionsPowerDesigned to Meet
MILTECH 9012managed12 x 10/100/1000M Copper6.55" X 5.67" X 2.2"166.4mm X 144mm X 56mm24VDC (18-70VDC), 13WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP68
MILTECH 9012Cmanaged12 x 10/100/1000M Copper6.54" X 5.67" X 2.68"166mm X 144mm X 68mm24VDC (18-72VDC), 25WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 9022managed12 x 10/100/1000M Copper
4 x 1/10G Fiber19" X 9.53" X 1.73"482.6mm X 242.06mm X 43.94mm24VDC (18-32VDC)
220VAC (90-230VAC), 20WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 9024managed24 x 10/100/1000M Copper19" X 10.63" X 3.47"482.6mm X 270mm X 88.1mm24VDC (18-32VDC)
220VAC (90-230VAC), 30WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 9028managed24 x 10/100/1000M Copper
4 x 1/10G Fiber19" X 11.18" X 3.49"482.6mm X 283.97mm X 88.65mm24VDC (18-32VDC)
220VAC (90-230VAC), 30WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
MILTECH 9116managed12 x 10G Copper
4 x 10G Fiber16.77" X 8.03" X 2.76"426mm X 204mm X 70mm24VDC (18-12VDC), 87WMIL-STD-1275, MIL-STD-704, MIL-STD-810, MIL-STD-461, IP67
